Ecoflam MULTIFLAM 500.1 PR TC VGD 20.503 — spare parts
- Output
- 1200–5000 kW
- Parts
- 12
- Factory code
- 3143783-3123860-3143080-3121384
- Series
- MULTIFLAM 500.1 · 12
Every part below fits this burner. Versions differ in valves and controls — check the factory code on the rating plate.
Parts that fit this burner
Burner components for Ecoflam MULTIFLAM 500.1 PR TC VGD 20.503 · 2
—on request
Sensors and switches for Ecoflam MULTIFLAM 500.1 PR TC VGD 20.503 · 2
—on request
—on request
Wiring, cables & electrical components for Ecoflam MULTIFLAM 500.1 PR TC VGD 20.503 · 2
—on request
—on request
Boiler components for Ecoflam MULTIFLAM 500.1 PR TC VGD 20.503 · 1
—on request
Boiler filters, gaskets & seals for Ecoflam MULTIFLAM 500.1 PR TC VGD 20.503 · 1
—on request
Burner pipes, flanges & connections for Ecoflam MULTIFLAM 500.1 PR TC VGD 20.503 · 1
—on request
Impellers for Ecoflam MULTIFLAM 500.1 PR TC VGD 20.503 · 1
—on request
Nozzle adapters for Ecoflam MULTIFLAM 500.1 PR TC VGD 20.503 · 1
—on request
Thermostats for Ecoflam MULTIFLAM 500.1 PR TC VGD 20.503 · 1
—on request
Specifications
Output1200–5000 kW
Gas connectionRp 2"
Fan motor power11000 W
Power consumption36500 W
Protection class (IP)IP55
Flame tube length354 mm
Flame tube diameter320 mm
Flame tube typeshort
Back pressure (combustion chamber)0–18 mbar
Gas consumption120–500 m³/h
Gas train pressure14–182 mbar
Noise level91.4 dB
Operating temperature-10–60 °C
Overall dimensions158.4 x 135.8 x 93.5 cm
Delivery scopewith combustion head, with gas train
Other versions of this seriesEcoflam MULTIFLAM 500.1 · 12
Parts often differ between versions of one series: pick the version named on your rating plate.
