Riello RL 130/M TC FS1 — spare parts
- Fuel
- Oil
- Output
- 498–1779 kW
- Parts
- 11
- Factory code
- 20166486
- Series
- RL 130/M · 2
Every part below fits this burner. Versions differ in valves and controls — check the factory code on the rating plate.
Parts that fit this burner
Burner components for Riello RL 130/M TC FS1 · 2
—on request
Boiler insulation for Riello RL 130/M TC FS1 · 1
—on request
Boiler pipes, flanges & connections for Riello RL 130/M TC FS1 · 1
—on request
Control boxes for Riello RL 130/M TC FS1 · 1
—on request
Control devices for Riello RL 130/M TC FS1 · 1
—on request
Flame sensors for Riello RL 130/M TC FS1 · 1
—on request
Ignition components for Riello RL 130/M TC FS1 · 1
—on request
Motors for Riello RL 130/M TC FS1 · 1
—on request
Oil valves for Riello RL 130/M TC FS1 · 1
—on request
Thermometers and manometers for Riello RL 130/M TC FS1 · 1
—on request
Specifications
FuelOil
Output498–1779 kW
Fan motor power2200 W
Supply voltage220 V
Power consumption2600 W
Net weight69 kg
Protection class (IP)IP44
Flame tube length272 mm
Flame tube diameter189 mm
Flame tube typestandard
Back pressure (combustion chamber)0–11 mbar
Overall dimensions95.2 x 70.5 x 55.5 cm
Delivery scopewith combustion head
Other versions of this seriesRiello RL 130/M · 2
Parts often differ between versions of one series: pick the version named on your rating plate.
- RL 130/M
2 parts · 20166486 - RL 130/M TC FS1
11 parts · 20166486
Questions about Riello RL 130/M TC FS1 parts
Which burner components fit Riello RL 130/M TC FS1?
These fit Riello RL 130/M TC FS1: Riello Fixing Bracket 3003495; Riello Spring 3012356. ↑
Which boiler insulation fit Riello RL 130/M TC FS1?
These fit Riello RL 130/M TC FS1: Riello Soundproofing 3003952. ↑
Which boiler pipes, flanges & connections fit Riello RL 130/M TC FS1?
These fit Riello RL 130/M TC FS1: Riello Flange Gasket 3003991. ↑
Which control boxes fit Riello RL 130/M TC FS1?
These fit Riello RL 130/M TC FS1: Riello Distribution Block 3012474. ↑
Which control devices fit Riello RL 130/M TC FS1?
These fit Riello RL 130/M TC FS1: Riello Fuel-Air Ratio Regulator 3012358. ↑
Which flame sensors fit Riello RL 130/M TC FS1?
These fit Riello RL 130/M TC FS1: Riello Flame sensor 20144943. ↑
