Riello RL 55/M BLU TC FS1 — spare parts
- Fuel
- Oil
- Output
- 190–712 kW
- Parts
- 10
- Factory code
- 20169338
Every part below fits this burner. Versions differ in valves and controls — check the factory code on the rating plate.
Parts that fit this burner
Burner components for Riello RL 55/M BLU TC FS1 · 3
Boiler insulation for Riello RL 55/M BLU TC FS1 · 1
—on request
Boiler pipes, flanges & connections for Riello RL 55/M BLU TC FS1 · 1
—on request
Control boxes for Riello RL 55/M BLU TC FS1 · 1
—on request
Control devices for Riello RL 55/M BLU TC FS1 · 1
—on request
Ignition components for Riello RL 55/M BLU TC FS1 · 1
—on request
Sensors and switches for Riello RL 55/M BLU TC FS1 · 1
—on request
Thermometers and manometers for Riello RL 55/M BLU TC FS1 · 1
—on request
Specifications
FuelOil
Output190–712 kW
Fan motor power1800 W
Supply voltage220 V
Net weight60 kg
Protection class (IP)IP44
Flame tube length365 mm
Flame tube diameter189 mm
Flame tube typestandard
Back pressure (combustion chamber)0–12.5 mbar
Overall dimensions104.5 x 66.3 x 55.5 cm
Delivery scopewith combustion head
Questions about Riello RL 55/M BLU TC FS1 parts
Which burner components fit Riello RL 55/M BLU TC FS1?
These fit Riello RL 55/M BLU TC FS1: Riello Fixing bracket 3003409; Riello Spring 3012356; Riello Bearing 3012357. ↑
Which boiler insulation fit Riello RL 55/M BLU TC FS1?
These fit Riello RL 55/M BLU TC FS1: Riello Soundproofing 3003952. ↑
Which boiler pipes, flanges & connections fit Riello RL 55/M BLU TC FS1?
These fit Riello RL 55/M BLU TC FS1: Riello Flange Gasket 3003991. ↑
Which control boxes fit Riello RL 55/M BLU TC FS1?
These fit Riello RL 55/M BLU TC FS1: Riello Distribution Block 3012474. ↑
Which control devices fit Riello RL 55/M BLU TC FS1?
These fit Riello RL 55/M BLU TC FS1: Riello Fuel-Air Ratio Regulator 3012358. ↑
Which ignition components fit Riello RL 55/M BLU TC FS1?
These fit Riello RL 55/M BLU TC FS1: Riello Igniter BG1210A + RF9.10 3003961. ↑
