Riello RS 70 TL FS1 — spare parts
- Fuel
- Gas
- Output
- 192–814 kW
- Parts
- 14
- Factory code
- 20194356
- Series
- RS 70 · 5
Every part below fits this burner. Versions differ in valves and controls — check the factory code on the rating plate.
Parts that fit this burner
Burner components for Riello RS 70 TL FS1 · 4
—on request
—on request
—on request
Burner pipes, flanges & connections for Riello RS 70 TL FS1 · 2
—on request
—on request
Actuators for Riello RS 70 TL FS1 · 1
433.78 EURexcl. VAT · import VAT and duties on delivery
Boiler filters, gaskets & seals for Riello RS 70 TL FS1 · 1
—on request
Boiler pipes, flanges & connections for Riello RS 70 TL FS1 · 1
—on request
Burners for Riello RS 70 TL FS1 · 1
—on request
Control boxes for Riello RS 70 TL FS1 · 1
226.43 EURexcl. VAT · import VAT and duties on delivery
Ionization & ignition electrodes for Riello RS 70 TL FS1 · 1
—on request
Sensors and switches for Riello RS 70 TL FS1 · 1
—on request
Thermometers and manometers for Riello RS 70 TL FS1 · 1
—on request
What is inside Riello RS 70 TL FS1
Components named in the manufacturer's documentation.
- LKS 210-21 in stock
- RMG88.62C2 in stock
- SIEMENS RMG88.62C2 in stock
- 3012023
- 3012024
- 3012025
- COMPACT 8/20 PM
- LGW 10 A2
- LKS 210
- RMG88
Specifications
FuelGas
Output192–814 kW
Firing stagesTwo-stage
Fan motor power1100 W
Power consumption1400 W
Net weight72 kg
Protection class (IP)IP40
Flame tube length385 mm
Flame tube diameter179 mm
Flame tube typeextended
Back pressure (combustion chamber)-0.9–8 mbar
Gas consumption19–81 m³/h
Noise level86 dB
Operating temperature0–40 °C
Overall dimensions122.5 x 51.1 x 55.5 cm
Delivery scopewith combustion head
Other versions of this seriesRiello RS 70 · 5
Parts often differ between versions of one series: pick the version named on your rating plate.
- RS 70
4 parts · 20194283 - RS 70 TC FS1
14 parts · 20194283 - RS 70 TC FS1 MB 412/1 - RT 20
12 parts · 3785102-3970144-3000843 - RS 70 TL FS1
14 parts · 20194356 - RS 70 TL FS1 MB 412/1 - RT 20
12 parts · 3785103-3970144-3000843
Questions about Riello RS 70 TL FS1 parts
Which burner components fit Riello RS 70 TL FS1?
These fit Riello RS 70 TL FS1: Riello Spring Retainer 3003880; Riello Mixing Device Head 3012028; Riello Gas Pressure Measurement Nipple 3012049; Riello Mounting Bracket 3012193. ↑
Which burner pipes, flanges & connections fit Riello RS 70 TL FS1?
These fit Riello RS 70 TL FS1: Riello Gas Connection Flange 3006803; Riello Gas Elbow 3012042. ↑
Which actuators fit Riello RS 70 TL FS1?
These fit Riello RS 70 TL FS1: Honeywell Servo motor B1-15S2 LKS210-21. ↑
Which boiler filters, gaskets & seals fit Riello RS 70 TL FS1?
These fit Riello RS 70 TL FS1: Riello Insulation Gasket 3012735. ↑
Which boiler pipes, flanges & connections fit Riello RS 70 TL FS1?
These fit Riello RS 70 TL FS1: Riello Flange Gasket 3003991. ↑
Which burners fit Riello RS 70 TL FS1?
These fit Riello RS 70 TL FS1: Riello Burner Igniter BG0910A + RF9.5 3003959. ↑
