Brahma Burner control (flame safeguard) 16020253

Brahma 16020253 is a burner control (flame safeguard) from the PEG01 series, designed for use in specific Brahma Master air heaters. It manages the complete ignition sequence, enforcing programmed safety times for pre-purge, ignition, fuel admission, and flame proving. The control reads signals from the air pressure switch and flame detector, and drives the ignition transformer, fuel valve, and fan. It supports ionisation, UV, and IR flame detection methods. This unit fits Brahma Master 4104.193 B35, B70 2013; B100, B150 2012-2013; and B150 DUAL VOL models.

Parts of this type are selected by matching the exact series and type designation, supply voltage, safety time values, pre-purge duration, and flame detection method (ionisation, UV, or IR). The base or plug pattern must also correspond. Controls are normally not interchangeable across series, even within the same brand; fitting a unit with mismatched safety times is a safety issue, not a matter of compatibility. Before ordering, verify the existing control's markings and the equipment's specifications.

When a control of this kind fails, the burner may fail to start, lock out during the safety time, or shut down unexpectedly. Common symptoms include no ignition spark, no fuel valve opening, or repeated lockouts. Check the flame detector, air pressure switch, and wiring connections, as these are common causes of control malfunction.
