Brahma Ignition transformer T11/A 15060001

This ignition transformer is intended for liquid or gaseous fuel burners. It operates at 220 V, 50 Hz, consuming 240 W. The secondary output is 9 kV at 20 mA, with a peak ignition voltage of 15 kV. It has a shell-type core, polyester resin insulation, and a radio interference suppression shield. Its dimensions are 150 x 101 x 100 mm, net weight 2 kg, and protection class IP00. The recommended spark gap is 3–5 mm, and the cable length is 550 mm.

When choosing a replacement of this type, verify that the supply voltage, frequency, output voltage and current, and duty cycle match the burner's requirements. The mounting system may vary between models; the part reference often includes a letter designating the mounting arrangement. Also confirm the type of high-voltage connection (screw terminal or cylindrical plug). Installation can be in any position. Ensure the transformer is grounded and that the ignition cable is kept as short as possible.
